-Travel speed laden/unladen: 4,4/4,9 km/h
-Turn radius: 1340 mm
-Lifting speed laden/unladen: 15/22 mm/s
-Lowering speed laden/unladen: 50/40 mm/s
-Maximum longitudinal gradient when driving (loaded/unloaded): 6%/16%

Electronics/Motor:
-Electronics: Curtis
-Drive motor: 0,75 kW
-Lift motor: 0,5 kW
-Lithium-ion battery: 24V/20Ah
-Charger: External, 8A
Capacity/kg: 1500
Length / Depth (mm): 1538
Width (mm): 540
Height (mm): 1125
Fork length (mm): 1150
Fork width (mm): 160
Fork height/thickness (mm): 50
Inner/other dimensions LxWxH (mm):
-Min. fork height: 80 mm
-Max. fork height: 195 mm
-Width over forks (outer edges): 540 mm
-Center of gravity separation: 600 mm
Weight (kg): 121
Color: Orange / Black
Material: Steel/Plastic/Polyurethane wheels/Lithium battery
Wheel data (Standard-/Steering wheels):
-Material, drive wheel: polyurethane
-Dimensions, drive wheel: 220 mm diameter, 70 mm width
-Electromagnetic brake
Wheel data (Fork wheels):
-Quantity: 4 (bogie)
-Material: polyurethane
-Dimensions: 80 mm diameter, 70 mm width
